Các kiểu máy bay

aircraft 2010


Boeing 737-400

aircraft
Door Distance from A/C Nose Door Size Sill Height
Number Metres Inches Metres Inches Metres Inches Metres Inches
A 4.67 184 0.76x1,65 30x65 2.62 103 2.77 109
B 5.03 198 0,86x1x83 34x72 2.62 103 2.77 109
C 28.93 1,139 0,76x1,65 30x65 2.62 103 2.67 105
D 28.93 1,139 0,76x1,83 30x72 2.62 103 2.67 105
E 8.53 336 1,22x0,89 48x35 1.27 50 1.40 55
F 24.99 984 1,22x0,84 48x33 1.37 54 1.73 54
ULD Configuration Bulk hold
Volume available for freight (based on full passenger loads) 24.0m3
Maximum weight 2,897kg
Boeing 737-800

aircraft
Door Distance from A/C Nose Door Size Sill Height
Number Metres Inches Metres Inches Metres Inches Metres Inches
A 4.76 1.84 0.76x1,65 30x65 2.62 103 2.77 109
B 5.03 1.98 0,86x1x83 34x72 2.62 103 2.77 109
C 28.93 1,139 0,76x1,65 30x65 2.62 103 2.67 105
D 2893 1,139 0,76x1,83 30x72 2.62 103 2.67 105
E 8.53 336 1,22x0,89 48x35 1.27 50 1.40 55
F 24.99 984 1,22x0,84 48x33 1.37 54 1.73 54
ULD Configuration Bulk hold
Volume available for freight (based on full passenger loads) 28.0m3
Maximum weight 2,600kg
Boeing 737-300/500

aircraft
Door Distance from A/C Nose Door Size Sill Height
Number Metres Inches Metres Inches Metres Inches Metres Inches
A 4.67 184 0.76x1,65 30x65 2.62 103 2.77 109
B 5.03 198 0,86x1x83 34x72 2.62 103 2.77 109
C 26.04 1,025 0,76x1,65 30x65 2.62 103 2.67 105
D 26.04 1,025 0,76x1,83 30x72 2.62 103 2.67 105
E 8.53 336 1,30x1,22 48x35 1.27 50 1.40 55
F 22.10 870 1,22x1,22 48x48 1.37 54 1.73 54
ULD Configuration Bulk hold
Volume available for freight (based on full passenger loads) 21.0m3
Maximum weight 2,250kg
Boeing 757-200

aircraft
Door Distance from A/C Nose Door Size Sill Height
Number Metres Inches Metres Inches Metres Inches Metres Inches
A 4.78 188 0.76x1,65 30x65 3.79 149 4.01 1.58
B 5.05 199 0,84x1x83 33x72 3.79 149 4.01 1.58
C 13.99 551 0,84x1,65 33x72 3.84 151 4.01 158
D 38.23 1,505 0,76x1,83 30x72 3.89 153 4.14 163
E 10.95 431 1,40x1,07 55x42 2.46 97 2.67 105
F 31.78 1,251 1,40x1,12 55x44 2.36 93 2.51 99
G 35.74 1,407 1,22x0,81 48x32 2.59 102 2.77 109
ULD Configuration Bulk hold
Volume available for freight (based on full passenger loads) 35.0m3
Maximum weight 5,000kg
Boeing 767-200

aircraft
ULD Configuration 7LD8/2LD7
Volume available for freight (based on full passenger loads) 46.0m3
Maximum weight 10,000kg
Boeing 767-300/300ER

aircraft
Door Distance from A/C Nose Door Size Sill Height
Number Metres Inches Metres Inches Metres Inches Metres Inches
A 5.72 255 1,07x1,83 42x72 4.14 163 4.50 177
B 5.72 255 1,07x1,88 42x74 4.14 163 4.50 177
C 42.55 1,675 1,07x1,83 42x72 3.99 157 4.39 173
D 42.55 1,675 1,07x1,88 42x72 3.99 157 4.39 173
E 11.30 445 3,40x1,70 134x67 2.29 90 2.57 101
F 12.32 485 1,78x1,70 70x67 2.29 90 2.57 101
G 37.29 1,486 1,78x1,70 70x67 2.18 86 2.52 99
H 40.62 1,599 0,97x1,89 38x43 2.21 87 2.59 102
ULD Configuration Bulk hold
Volume available for freight (based on full passenger loads) 63.0m3
Maximum weight 16,500kg
Boeing 777-200

aircraft
Door Distance from A/C Nose Door Size Sill Height
Number Metres Inches Metres Inches Metres Inches Metres Inches
A 6.74 266 1,07x1,88 42x74 4.71 185 5.00 197
B 17.07 672 1,07x1,88 42x74 4.88 192 5.07 200
C 36.32 1,430 1,07x1,88 42x74 5.16 203 5.30 209
D 49.53 1,950 1,07x1x88 42x74 5.28 206 5.53 218
E 11.80 465 2,69x1x70 106x67 2.81 111 3.05 120
F (s) 41.25 1,624 1,78x1,70 70x67 3.23 127 3.40 134
*F(I) 41.77 1,645 1,70x2,69 67x106 3.23 127 3.41 134
G 46.32 1,824 0,91x1,14 36x45 3.39 133 3.61 142
ULD Configuration 4AKE +6PAG+Buld holds
Volume available for freight (based on full passenger loads) 80m3
Maximum weight 14x000kg
Boeing 747-300

aircraft
ULD Configuration 12LD3/6LD7
Equipment available for freight (based on full passenger loads) 6LD7+Bulkhold
Volume available for freight (based on full passenger loads) 70.0m3
Maximum weight 20,000kg
Boeing 747-400

aircraft
ULD Configuration 14LD3/6LD7
Equipment available for freight (based on full passenger loads) 6LD7+1LD3+Bulkhold
Volume available for freight (based on full passenger loads) 69.20m3
Maximum weight 21,000kg
Boeing 747-400 Freighter

aircraft
ULD Configuration 30LD3/9LD7
Equipment available for freight (based on full passenger loads) 30M1/9LD7
Volume available for freight (based on full passenger loads) 764.5m3
Maximum weight

115,000kg (400series)
Airbus 321-200

aircraft
Door Distance from A/C Nose Door Size Sill Height
Number Metres Inches Metres Inches Metres Inches Metres Inches
A 5.02 198 0.81x1.85 32x73 3.43 135 3.45 137
B 8.82 1,167 0.81x1.85 32x73 3.46 136 3.54 139
C 36.57 1,440 0.81x1.85 73x32 3.54 139 3.73 147
D 8.16 321 1.82x1.23 71.5x48 2.03 80 2.09 82
E 29.72 1,170 1.82x1.23 71.5x48 2.11 83 2.26 89
F 33.22 1,370 0.86x0.94 34x37 2.34 92 2.51 99
ULD Configuration 4PAG + Bulk hold
Volume available for freight (based on full passenger loads) 30.0m3
Maximum weight 5,000kg
Airbus 320-200

aircraft
Door Distance from A/C Nose Door Size Sill Height
Number Metres Inches Metres Inches Metres Inches Metres Inches
A 5.02 198 1,85x0,81 73x32 3.42 135 3.47 137
B 29.04 1,167 1x85x0,81 73x32 3.55 140 3.73 147
C 8.16 321 1,23x1,82 48.3x71.5 2.03 80 2.09 82
D 22.69 893 1,23x1,82 48.3x71.5 2.11 83 2.25 88.50
E 26.29 1,035 0,86x0,94 34x37 1.27 92.5 2.51 99
ULD Configuration 7AKH + Bulk hold
Volume available for freight (based on full passenger loads) 30.0m3
Maximum weight 5,000kg
Airbus 330-200

aircraft
Door Distance from A/C Nose Door Size Sill Height
Number Metres Inches Metres Inches Metres Inches Metres Inches
A 5.85 230 1.07x1.93 42x76 4.40 175 4.58 180
B 17.74 698 1.07x1.93 42x76 4.69 184 4.86 191
C 46.68 1,838 1.07x1.93 42x76 5.47 215 5.70 224
D 9.53 375 1.07x2.70 70x106 2.58 101 2.73 107
E 40.09 1,579 2.73x1.68 107.5x66 3.22 127 3.45 136
F 43.07 1,696 0.95x0.95 37.4x37.4 3.36 132 3.58 141
ULD Configuration 4LD7+4LD3+Bulk hold
Volume available for freight (based on full passenger loads) 66.8m3
Maximum weight 14,100kg
Airbus 340-300

aircraft
Door Distance from A/C Nose Door Size Sill Height
Number Metres Inches Metres Inches Metres Inches Metres Inches
A 5.85 230 1.93x1.07 76x42 4.41 175 4.59 180
B 17.74 698 1.93x1.07 76x42 4.67 184 4.84 190
C 50.95 2,005 1.93x1.07 76x42 5.47 215 5.73 226
D 9.53 375 2.70x1.70 106x70 2.58 101 2.73 107
E 44.36 1,746 2.73x1.68 106x70 3.23 127 3.44 135
F 47.34 1,864 0.95x0.95 37.4x37.4 3.35 132 3.58 141
ULD Configuration 7PAG + Bulk hold
Volume available for freight (based on full passenger loads) 70.0m3
Maximum weight 16,000kg
